Industrial Cooking and Chilling Line Scale Model

28.5" L x 8.5" W x 8" H

This scale industrial model reproduces a modular advanced high-speed cooking system for rice, pasta, potatoes, vegetables and grains. Perforated guard panels run the length of this industrial cooking line; Lift them off and the machine underneath lies open.

With the grates removed, the interior detail is all there: a curved, perforated cooking basket, angled chutes, and valve fittings along the top rail. Open guard frames keep the outline of the machine intact, so the line still reads as one piece. Below, the tank cabinet is divided into six access panels with round fasteners, and three drain spouts turn down toward the deck. A to-scale worker in blue overalls stands at the loading end beside the control station.

Three parts are built to be handled at the booth:

Removable grates that open up the tanks and baskets
Movable basket machines
A removable tote bin lift

The model measures 28.5" L x 8.5" W x 8" H and sits on a deep base with a light gray top and black sides. A production line belongs on a factory floor. This version lets the customer's team open it up and walk a prospect through it, section by section.
